Instructions for setting up and managing Network Bridge on Windows 10

When there is no port available on the router, Wifi cannot be connected. In this case you can use Network Bridge on Windows 10 to join other computers to the network connection.

Network Bridge is an integrated feature for a long time on Windows. Bridge allows you to connect 2 or more Network Segments together to allow devices to connect to the network in case it cannot be directly connected on the Router or Switch.

1. Some notes before starting

Before starting to set up Bridge Connection on Windows 10, you need at least 2 network adapters. One to use the Internet connection and one to connect to another computer.

Also when setting up Connection Bridge on Windows 10 (or on previous Windows versions), the main network adapter on the server will lose Internet connection.

To regain access to the Internet, you must set up a static IP address (Static IP address) manually.

The first thing you need to do is save the current IP address information of the DHCP server on the local network (Local Netwrok).
To view the current IP address information, follow the steps below:

1. Press Windows + X key combination to open the Power User Menu and select Command Prompt.

2. Enter the command line below into the Command Prompt window and press Enter:

ipconfig / all

3. Note again configuring the IP address that the network adapter (Network Adapter) connects to the Internet.

Note some information such as: IPV4, subnet mask, default gateway, and DNS servers address.

Instructions for setting up and managing Network Bridge on Windows 10 Picture 1

2. How to create Network Bridge on Windows 10?

1. Press Windows + X key combination to open the Power User Menu, then select Network Connections .

2. Select both the network adapter (network adapter) connected to the Internet and the network adapter you want to use to connect Bridge.

3. Right-click and select Bridge Connections .

Instructions for setting up and managing Network Bridge on Windows 10 Picture 2

At this point, the devices connected on the Bridge port can access the network and the Internet with the router IP address information. However, the Bridge host computer cannot access the Internet unless there is a 3rd network adapter connected to the network or a static IP address.

3. How to regain Internet access after setting Bridge?

To access the Internet connection right from the server, follow the steps below:

1. Press Windows + X key combination to open the Power User Menu and select Network Connections.

2. Right-click the Adapter Bridge and select Properties .

Instructions for setting up and managing Network Bridge on Windows 10 Picture 3

3. Select the network adapter to connect to the Internet.

4. Select Internet Protocol Version 4 (TCP / IPv4) .

5. Click Properties.

Instructions for setting up and managing Network Bridge on Windows 10 Picture 4

6. Select the Use the following IP address option .

7. Use the IP address information that you note in the above instructions to assign to a static IP address.

Instructions for setting up and managing Network Bridge on Windows 10 Picture 5

7. Click OK .

8. Click Close to finish.

4. How to add one or more other network adapters to Network Bridge?

1. Right-click the network adapter and select Add to Bridge .

Instructions for setting up and managing Network Bridge on Windows 10 Picture 6

2. Connect a game controller or another computer, the device will automatically be set up from the local Router (Local Router).

5. Delete the Bridge setting from the computer

If you do not need to use the Bridge connection, you can select 1 or select all network adapters and then select Remove from Bridge.

Instructions for setting up and managing Network Bridge on Windows 10 Picture 7

Now you can see that the Adapter Bridge no longer appears on Network Connections. If the Adapter Bridge still appears, you only need to restart your computer.

The final step is to proceed with deleting the static IP address setting.

1. Right-click the network adapter, and then select Properties .

2. Select Internet Protocol Version 4 (TCP / IPv4) .

3. Click Properties .

4. Select the Obtain an IP address option automatically .

5. Select Obtain DNS server address automatically .

Instructions for setting up and managing Network Bridge on Windows 10 Picture 8

6. Click OK .

7. Click Close to complete the process.
