Details are given in Microsoft's ADV190005 security recommendation as follows:
"HTTP / 2 allows the client to specify any number of SETTINGS frames with any number of SETTINGS parameters. However, in some cases, excessive installation may cause services to become unstable. and thus lead to CPU usage temporarily spike until the connection time runs out and the connection is closed ".
As a way to improve the situation, Redmond's security team "has added the ability to specify thresholds for the number of HTTP SETTINGS / 2 in the request", threshold levels must be set by the IIS administrator after evaluation. The environment and HTTP / 2 on their systems require protocols, as they will not be preconfigured by Microsoft.
To set these limits, Microsoft has added the following registry entries to vulnerable Windows 10 releases:
Path:
ComputerHKEY_LOCAL_MACHINESYSTEMCurrentControlSetServicesHTTPParameters
Name : Http2MaxSinstallPerFrame
Type : DWORD
Data : The minimum supported value is 7 and up to 2796202. Value outside the range is cut to the corresponding minimum / maximum end value.
Path:
ComputerHKEY_LOCAL_MACHINESYSTEMCurrentControlSetServicesHTTPParameters
Name : Http2MaxSettingsPerMinute
Type : DWORD
Data : The minimum supported value is 7. The smaller value is cut to the minimum value.
After the thresholds are placed on the Windows system running IIS, the connections will be immediately canceled if:
Besides, according to Microsoft, it should be noted that you may have to restart the service or restart the server so that the newly added registry values can be read.
Running Windows servers that were previously exploited by the attacker with the help of zero-day in IIS 6.0 will affect WebDAV services by default in all IIS distributions, from July 7 2016 to March 2017.
