How to use Nagakawa 1 way, 2 way controller properly, save power

How to use Nagakawa air conditioner correctly and save electricity? Instructions on how to use 1-way, 2-way Nagakawa control that we share in this article will help you!

Symbols, function buttons on Nagakawa air conditioner

Control Nagakawa air conditioner is composed of 2 parts, the screen and the function keys.

Around the control screen have the following symbols:

1. AUTO: Automatic mode.
2. COOL: Cooling mode.
3. DRY: Dehumidification mode.
4. FAN: Fan mode.
5. HEAT: Hot mode (also known as heating mode, this mode is only available in Nagakawa 2-way air conditioner).
6. FAN SPEED: Fan speed.
7. AIR SWING: Wind propeller
8. ON TIMER: Timer to turn on the air conditioner.
9. OFF TIMER: Timer to turn off the air conditioner.

Function keys on Nagakawa air conditioner remote include:

1. ON / OFF button: Turn on / off air conditioner.
2. MODE button: Selecting the basic features of the air conditioner (AUTO, COOL, DRY, FAN, HEAT).
3. FAN SPEED button: Adjust the fan speed.
4. LOUVER button: Quick cooling.
5. Up arrow TEMP button: Increase the temperature.
6. Button TEMP shaped downward: Reduce the temperature.
7. SWING button: Adjust the swing fan.
8. ON button on the TIMER frame: Air conditioning timer.
9. OFF button on the TIMER frame: Air-conditioning timer.
10. Up arrow button on TIMER frame: Increase the time when the timer.
11. Down arrow button on TIMER frame: Reduce time when the timer.
12. SLEEP button: Sleep mode.
13. IONIZER button: Function to create negative ions.
14. RESET button: Restore original settings.

How to use Nagakawa 1 way, 2 way controller properly, save power Picture 1

Control Nagakawa air conditioner

How to use Nagakawa air conditioner controller 1 way, 2 way

Although Nagakawa 1-way air-conditioner and Nagakawa 2-way air conditioner are two different types of air conditioners, the control way to adjust the modes is almost the same.

How to turn on / off Nagakawa air conditioner

1. Press ON / OFF button 1 time to turn on air conditioner.
2. Press ON / OFF button once more if you want to turn off the air conditioner.

Refer to: 4 ways to turn on the air conditioner without using the control

Select the basic mode

Nagakawa air conditioner has 5 main operating modes, including: AUTO mode (air conditioner maintains the room temperature at 23 - 25 degrees C), COOL cooling mode, DRY desiccant mode, DRY mode FAN fan and HEAT heating mode (2-way air conditioner only). To select these modes, you need to press the MODE button until the arrow on the monitor screen points to the corresponding mode.

How to adjust the air conditioner Nagakawa

When Nagakawa air conditioner operates in cooling or heating mode, users can customize the temperature between 16 and 30 degrees C. To set the temperature, you:

1. Press the TEMP button with an upward arrow to raise the temperature.
2. Press the TEMP button in the downward-facing arrow to reduce the temperature.

How to adjust the fan speed

You can adjust the fan speed by pressing the FAN SPEED button, where:

1. Press the FAN SPEED button once to select low fan mode.
2. Press the FAN SPEED button twice to select the average fan mode.
3. Press FAN SPEED button 3 times to select high fan mode.
4. Press the FAN SPEED button 4 times to select the auto fan mode AUTO FAN.

How to adjust the wind direction

To adjust the air direction, press the SWING button once. At this time, the air conditioning fan blades will move up and down automatically. If you want the propeller to stop somewhere, press the SWING button once more.

How to use SLEEP sleep mode

SLEEP mode is suitable for use at night. To operate this mode, press the SLEEP button on the Nagakawa air conditioner.

1. If you select SLEEP mode when the air conditioner is cooling, in the first 2 hours, every hour the air conditioner will adjust itself by 1 degree, then will maintain that temperature until the machine is turned off.
2. If the SLEEP function is activated while the air conditioner is warming, the first 2 hours, every 30 minutes it will adjust the temperature by 1 degree, then maintain this temperature until the shutdown.

How to schedule Nagakawa air conditioner

Timer turn on the air conditioner

When the Nagakawa air conditioner is turned off, to do the timer, you need to do the following:

1. Step 1: Press the TIMER ON button.
2. Step 2: Use the up and down arrow buttons on the TIMER frame to increase and decrease the time you want to set.
3. Step 3: Press the TIMER ON button again to confirm the setting.

Timer off air conditioner

When Nagakawa air conditioner is on, to turn off the timer, do the following:

1. Step 1: Press the TIMER OFF button.
2. Step 2: Press the 2 up and down arrow buttons on the TIMER frame to increase or decrease the time you want to set.
3. Step 3: Press the TIMER OFF button again to confirm the setting.

How to use Nagakawa 1 way, 2 way controller properly, save power Picture 2

Using remote Nagakawa air conditioning is not difficult

How to save electricity when using Nagakawa air conditioner

Here are some 'tips' to help you save energy when using Nagakawa air conditioner:

1. Only turn on the air conditioner when necessary, do not use the air conditioner all day.
2. Limiting the air conditioner temperature adjustment too much difference from the environment (maximum deviation of 10 degrees, ideally ideally should be between 25 and 28 degrees C).
3. Close the doors during the use of air conditioning, but do not need to close too tightly to avoid clogging.
4. Use additional fans, nebulizers to humidify the air-conditioned room.
5. Periodically cleaning and maintaining the air conditioner is always durable and efficient.

How to use Nagakawa 1 way, 2 way controller properly, save power Picture 3

Should clean, maintain regular air conditioning

Above is how to use 1-way, 2-way Nagakawa control that we want to share with you. Thank you for your interest and follow the article!
