The Size of the Main Door 2 Wings, 4 Wings

The size of the main door has 2 wings including 1 large wing, a small wing

Common sizes of 2 doors irregular wings including:

HeightWidthBigwing Baby wing 2120mm 1090mm 690mm 400mm 2120mm 1260mm 810mm 450mm

For 4.5cm molded door, the width of 90mm and the height of 45mm are added. If the door has a 6cm mold, the door size will increase by 60mm for the door height and 120mm for the door width.

The size of the main door 2 wings evenly

The door frame is 4.5cm thick, the height of the door (including the door frame) is 2165mm and the width is 1180-1380 - 1620-1850mm

The door frame is 6cm long, the height (including the door frame) is 2180mm and the width is 1210 - 1380 - 1650 - 1880mm.

The size of the main door 4 wings evenly

DoorframeHeightincluding frameWidth 4.5cm 2165mm 2450, 2640, 2710, 2910, 3500, 3690mm 6cm 2180mm 2480, 2670, 2740, 2940, 3530, 3720 mm

The size of the main door 4 wings are not the same

With 4.5cm thick mold, the door size without mold is the door height of 2165mm and the width of 1850 - 2200mm.

With a 6cm-thick mold, the size of the door without mold is 2180mm high and 1880-2222mm wide.

Main door size 1 wing

The one-door main door is often used as a door for each room or back door. The standard dimensions for the 1-leaf doors are as follows:

Height: 212cm (width: 210.6 cm - 214.8 cm) Width: 81cm (width: 80.8 cm - 82.6 cm).

With a 4.5cm thick mold:

Width is 81cm + 4.5cm left frame + 4.5cm right frame. Height: 212cm + 4.5cm above frame.

With a 6 cm thick mold:

Width: 81cm + 6cm left frame + 6cm right frame. Height: 212cm + 6cm above frame.
